Our PCB high-precision exposure machine is the core imaging equipment for printed circuit board manufacturing. It is specially developed for high-precision pattern transfer processes of PCB inner and outer layer circuits, solder mask layers, and silkscreen printing. Equipped with advanced parallel light exposure technology and an intelligent automatic alignment system, the equipment effectively eliminates pattern distortion and position deviation caused by traditional exposure processes. It delivers stable and high-quality imaging results for standard PCBs, multi-layer boards, HDI boards, aluminum substrates, PTFE high-frequency boards, and heavy copper boards, fully meeting the PCB manufacturing demands of consumer electronics, automotive electronics, industrial control, communication equipment and other industries.
Core Advantages
Ultra-high Precision and Stable Imaging: Adopting a high-uniformity parallel light source to minimize light diffraction, the machine supports ultra-fine line and space exposure processing. Combined with an automatic visual positioning system, it achieves excellent alignment accuracy, significantly improves the yield of fine circuit production, and avoids quality defects such as open and short circuits caused by exposure offset.
Strong Material Compatibility: Compatible with various PCB substrates including FR-4, aluminum substrates, ceramic substrates, and high-frequency microwave materials. It supports the exposure of thin-core boards, ultra-thin boards and heavy copper boards, and realizes flexible production covering both prototype sampling and mass production.
High Yield and Cost Efficiency: With uniform illumination and stable exposure energy, it ensures consistent pattern depth and texture. It effectively reduces defective products such as insufficient exposure, virtual printing and blurred patterns, greatly lowers material loss and rework costs, and improves overall production efficiency.
Intelligent and User-friendly Operation: Integrated with an intelligent human-machine interaction system that supports parameter memory, one-click start and automatic fault alarm. Featuring simple operation and low learning threshold, the equipment supports long-term stable continuous operation, fully adapting to large-scale industrial production.
Durable and Low Maintenance: Adopting high-quality light sources and precision mechanical components with long service life and extremely low energy attenuation. The industrial dust-proof and anti-corrosion structural design adapts to complex factory environments, effectively reducing daily maintenance frequency and operating costs.
Technical Parameters
Exposure Area: Maximum processing size can be customized according to production requirements
Operation Mode: Automatic alignment, dual manual and automatic modes
Company Equipment Strength
To ensure high-volume, high-precision and stable PCB production and delivery capacity, our company is equipped withdozens of brand-new high-precision parallel light exposure machines, all of which are mainstream high-end industrial equipment with standardized and large-scale layout. All exposure machines undergo professional debugging and regular calibration, maintaining industry-leading precision stability and equipment availability rate. The equipment cluster supports simultaneous production of multiple batches and diverse PCB orders, effectively solving common industry pain points such as slow prototype delivery, insufficient mass production capacity, and unstable precision for high-end boards. Supported by complete exposure equipment clusters and a full set of front and back-end production and testing equipment, we are capable of efficient full-process precision manufacturing for multi-layer boards, HDI boards, heavy copper boards, high-frequency boards and other high-end PCB products. We stably guarantee delivery efficiency, product yield and quality consistency, and fully meet the high-standard, large-volume and urgent customized production requirements of global customers, demonstrating our strong comprehensive manufacturing strength.
Application Scope
This high-precision exposure machine is widely used in precision prototyping and mass production of various printed circuit boards. It serves as essential core manufacturing equipment for automotive electronic PCBs, 5G communication base station boards, industrial control mainboards, medical device circuit boards, smart consumer electronic PCBs and other high-end electronic products, providing reliable precision assurance for high-quality PCB deliveries.
